Kinesis FF29 Frame and Fork 45% off - Was £1315 Now £723.25

Regular price £723.25 GBP Sale price £1,315.00
On Sale

Tax included

Shipping calculated at checkout

SKU: K-RS-FF29-KB-L1-INC-MCQEEN
Colour: Black
Size

Only 1 in stock


Our FF29 is now even faster – we are now offering our latest Kinesis FF29 aluminium hardtail mtb frame with an X-Fusion fork and headset. This kit includes any FF29 frameset of your choice, a set of X-Fusion McQueen HLR 140mm forks, and a sealed Kinesis headset. We are offering this new FF29 frame and fork kit at a 45% discount off the total price. Here's what's included in the new kit:

FF29 FRAMESET SRP £600
The FF29, initially launched in 2012, garnered multiple magazine reviews and awards. For 2024, it's been re-designed and re-introduced – longer, lower, and faster. Our modern hardtail bike comes with updated geometry, new aluminium tubing technology, functional external cable routing and is packed with trail-focussed features. The frame is sized by reach and is designed to be used with a dropper post. Complete with a 65.5º head angle and steep seat-tube, the all-new FF29 remains nimble and agile for singletrack riding, ideal for all-day hard-charging descents and goat-like climbing. With its long, low, and stable design and generous reach numbers, the FF29 lives up to its reputation as Furiously Fast.

X-FUSION MCQUEEN HLR 140mm FORKS SRP £650
The FF29 kit comes with the new X-Fusion McQueen 34 29"/27.5+ HLR Boost fork, prioritising stiffness without adding excess weight. Weighing just over 2100 grams, the McQueen offers an exceptional stiffness-to-weight ratio. The Roughcut Damper provides high and low-speed compression and rebound damping adjustment, making these forks plush and responsive on the trails.

KINESIS HEADSET SRP £55
Integrated Tapered Headsets for Kinesis frames.

DELIVERY INFORMATION
Due to frame checks before dispatch, this may add 4-5 days to the delivery time.

Features

The FF29 uses Kinesis’s advanced SPF — Super Plastic Forming. Most manufacturers use hydroformed tubes, but with SPF we can create lighter aluminium tubes and more intricate shapes that will build into a lighter and stiffer frameset.


Geometry designed for every ride — The FF29 is long, low and stable with a steep seat tube & long reach numbers. Despite this, it’s not ‘slack’ or slow handling thanks to a head angle of 65.5º providing a nimble/agile feel at the bars for singletrack hacking.


Flexible setup — Horizontally adjustable dropouts allow you to fine-tune the FF29’s chainstay length for how you ride, with the added benefit of single-speed capability.


Size by Reach — Choose a size based on your riding style and fit preference rather than your height.
Easy external cable routing — Externally routed cables make servicing easy and allow the use of a full-length outer cable to ensure your FF29 will run through a UK Winter.


GW Switch Lever Thru Axles — Clean and simple design with a removable lever

Specification

FRAME: SPF 6061 aluminium tubing
CHAIN LINE: 52mm
TYRE CLEARANCE: for 29 x 2.5in tyres
REAR AXLE: 148 x 12mm Boost rear axle spacing
BOTTOM BRACKET: BB92 BB shell
SEATPOST: 31.6mm seat post required.
FRONT MECH: 34.9mm front mech clamp required.
HEADSET REQUIRED: Tapered integrated
AXLES: GW ‘Switch Lever’ rear axle.
WEIGHT: 2.0kg (L3 frame)
FRAME SUPPLIED WITH: dropouts, rear axle, seat clamp and cable guides
WARRANTY: 5 years.

Geometry - FF29

Frame Size L1 L2 L3 L4

Seat Tube Length 370 395 425 465
Top Tube Length (Effective) 593 620 640 667
Head Tube Length 100 111 120 127
Head Tube Angle 65.5 65.5 65.5 65.5
Seat Tube Angle 76 76 76 76
Bottom Bracket Drop 63 63 63 63
Chain Stay Length (shortest) 435 435 435 435
Front Centre 753 782 804 832
Wheelbase (shortest) 1181 1210 1232 1253
Stack 632 642 650 657
Reach 435 460 478 503
Fork Axle to Crown 551 551 551 551

Additional Info

Sizes: L1, L2, L3, L4

Colours: Orange or Black Bronze

Loading image:

Kinesis FF29 Frame with X-Fusion 140mm Forks - 45% off
